Cranberry Lake Village
Cranberry Lake Village consists of a vast residential subdivision among the 100 year-old pine trees, with both permanent and vacation homes. The Lillypad outdoor waterpark is near these accommodations. It includes two waterslides, activity pool, kiddie pool with a frog slide and mushroom, game room, snack bar, swimming beach, swan paddle boat rentals and the largest hybrid skatepark in the State of Wisconsin.
Manchester Place Senior Housing Development
The construction drawings for this three story, 31,000 sq. ft., 74-unit senior housing development included ADA accessibility, balcony design, entry canopy, sanitary and HVAC design, site grading and parking lot design, lighting, landscaping, retro-fitted trash chute, and beauty salon design. The parking lot lighting plan was designed to direct all lighting away from public streets and not to exceed 3 foot candles at the property line.
The services provided included a geotechnical study; site, lighting, and parking lot design; all necessary detailing, schedules, and specifications for construction purposes; and submittal of final building and site plans and all necessary calculations to the Wisconsin Department of Commerce for review and approval.
Lake Delton, Wisconsin
Phase III of the 3+ acre expansion to the existing Ny-Um-Ba condominiums consisted of the design of site improvements (grading, storm drainage, water, sanitary sewer, road extension and street lighting). The project had limitations of space and elevations, which made typical detention areas impractical. The approach used to address the additional runoff generated by these improvements was the design and installation of bioretention areas. Two infiltration basins were designed to process all runoff generated in these areas.
The master plan for this new three story, 26,000 SF, 54-unit luxury apartment building included multiple schematic designs for the developer to review and consider. Once a design was approved, we assisted the developer with planning and council meetings for the City of Baraboo.
A (PUD) Planned Unit Development was pursued through the city allowing the Owner to put 54 units on one property instead of the 4 units as zoned. Major building components include: underground parking, a mix of one and two unit luxury apartments, privacy balconies, brick facade and cut-off parking lot lighting.
The services provided included master planning; building design; civil and structural engineering; and associated construction administration.
Tuscan Ridge Condominiums
This 10+ acre condominium development was laid out to create a "community within a community", encouraging interaction between its residents. The Tuscan Ridge Condominiums border the Yahara River and its unspoiled wetland areas. Ramaker & Associates’ civil team created a planned-unit development that could maximize the available space without disrupting the surrounding wetland areas. The development includes 15 two-unit condominium buildings and required storm sewer, stormwater detention ponds, parkland, bike paths, street, sanitary sewer and water main construction.
